The BS66F340C / BS66F350C / BS66F360C series is a high-performance 8-bit Flash microcontroller family designed for modern capacitive touch applications. Featuring built-in touch key capability, advanced A/D conversion, and robust system protection, this series is ideal for home appliances, instruments, and consumer electronics.

CPU Features

• Operating Voltage Range:

• fSYS = 4MHz: 2.2V ~ 5.5V

• fSYS = 8MHz: 2.2V ~ 5.5V

• fSYS = 12MHz: 2.7V ~ 5.5V

• fSYS = 16MHz: 3.3V ~ 5.5V

• High-Speed Operation:

• Instruction cycle as fast as 0.25μs at 16MHz system clock with VDD = 5V

• Power Efficiency:

• Power-down and wake-up modes for reduced power consumption

• Multi-mode operation: FAST, SLOW, IDLE, and SLEEP

• Flexible Oscillator Options:

• External High-Speed Crystal (HXT)

• Internal High-Speed RC Oscillators: 8MHz, 12MHz, 16MHz (HIRC)

• Internal Low-Speed 32kHz RC (LIRC)

• External 32.768kHz Crystal (LXT)

• Fully integrated internal oscillators — no external components required

• Efficient Instruction Set:

• All instructions execute in 1–3 cycles

• 115 powerful instructions

• Support for table read operations

• Up to 12-level subroutine nesting

• Bit manipulation instructions

Peripheral Features

• Memory:

• Flash Program Memory: 4K×16 to 16K×16

• RAM: 512×8 to 1024×8

• True EEPROM: 128×8

• In-Application Programming (IAP) supported

• System Protection:

• Watchdog Timer (WDT)

• Low Voltage Reset (LVR)

• Low Voltage Detection (LVD)

• I/O Capability:

• Up to 46 bidirectional I/O lines

• Programmable current source/sink for LED drive applications

• Two external interrupt lines (shared with I/O pins)

• Timers & PWM:

• Time measurement

• Input capture

• Compare match output

• PWM and single pulse generation

• Multiple timer modules supporting:

• Dual Time-Base support for fixed-interval interrupt signals

• Analog Features:

• 8-channel 12-bit A/D converter

• Internal reference voltage (VBG)

• Touch Key Integration:

• Supports up to 28 fully integrated capacitive touch keys

• No external components required for touch sensing

• Communication Interfaces:

• Serial Interface Module (SIM) for SPI or I2C

• UART: Full-duplex asynchronous communication

• Package Types:

• 28-pin SSOP

• 44-pin and 48-pin LQFP

Application Scenarios

Thanks to its high integration and reliability, this series is ideal for:

• Smart Remote Controllers

• Household Appliances (e.g., rice cookers, water kettles, coffee machines)

• Measurement Instruments and Digital Panels

• Smart Plugs and Small Home Automation Devices

• Consumer Electronics with Capacitive Key Interfaces
