Features:

4 Attenuator Products:

2, 3, 4 & 6 dB Fixed Attenuation Levels

Wide Bandwidth: DC - 25 GHz

Excellent Attenuation Accuracy

Power Handling: +25 dBm

6 Lead 2x2 mm SMT Package: 4 mm2

General Description:

The HMC652LP2E / 653LP2E / 654LP2E / 655LP2Eare a line of wideband fixed value SMT 50 Ohmmatched attenuators which offer attenuation levelsof 2, 3, 4 and 6 dB respectively. These passiveattenuators are ideal for military, test equipment, andother wideband applications where extremely flatattenuation, and excellent VSWR vs. frequency arerequired.These wideband attenuators handle up to +25 dBmof input power, and are compatible with high volumesurface mount manufacturing techniques.

Typical Applications:

The HMC652LP2E - HMC655LP2E are ideal for:

• Fiber Optics

• Microwave Radio

• Military & Space

• Test & Measurement

• Scientific Instruments

• RF / Microwave Circuit Prototyping
