ICM-42605 HIGHLIGHTS:

The ICM-42605 is a 6-axis MEMS MotionTrackingdevice that combines a 3-axis gyroscope and a3-axis accelerometer. It has a configurable hostinterface that supports I3CSM, I2C and SPI serialcommunication, features a 2 kB FIFO and 2programmable interrupts with ultra-low-powerwake-on-motion support to minimize systempower consumption.The ICM-42605 supports the lowest gyro andaccel sensor noise in this IMU class, and has thehighest stability against temperature, shock (upto 20,000g) or SMT/bend induced offset as wellas immunity against out-of-band vibrationinduced noise.Other industry-leading features includeInvenSense on-chip APEX Motion Processingengine for gesture recognition, activityclassification, and pedometer, along withprogrammable digital filters, and an embeddedtemperature sensor.The device supports a VDD operating range of1.71V to 3.6V, and a separate digital IO supply,VDDIO from 1.71V to 3.6V.

ICM-42605 FEATURES:

• Gyroscope Noise: 3.8 mdps/Hz &Accelerometer Noise: 70 µg/Hzo Low-Noise mode 6-axis currentconsumption of 0.65 mA

• User selectable Gyro Full-scale range (dps):± 15.2/31.2/62.5/125/250/500/1000/2000

• User selectable Accelerometer Full-scalerange (g): ± 2/4/8/16

• User-programmable digital filters for gyro,accel, and temp sensor

• APEX Motion Functions:o Pedometer, Tilt Detection, Tap Detectiono Wake on Motion, Raise to Wake/Sleep,Significant Motion Detection

• Host interface: 12.5 MHz I3CSM, 1 MHz I2C,24 MHz SPI

APPLICATIONS:

• Smartphones, Computers, Tablets

• Smart Watches and Fitness Trackers

• Augmented & Virtual Reality Headsets andControllers

• Game Controllers

• IoT Applications

• Drones and Robotics
