Overview：

The Molex 46625-0600 is a 6-circuit, single-row, panel-mount plug housing from the Micro-Fit 3.0 BMI (Blind Mating Interface) family. Designed for wire-to-wire and wire-to-board power distribution applications, this connector features a 3.00 mm (0.118 inch) pitch and accepts male pin crimp terminals (sold separately). The blind mating interface allows for smooth, tolerant connections even when connectors are not easily visible during assembly, reducing installation time and preventing damage to pins and housings. Rated for operation from -40°C to +105°C and constructed with UL94V-0 black polyamide material, the 46625-0600 delivers reliable performance in moderate-temperature environments.

Features：

Feature： Description

Circuit Quantity： 6 circuits (positions)

Row Configuration： Single row

Pitch (Center Spacing)： 3.00 mm (0.118 inches)

Connector Type： Plug housing (male pin housing)

Mounting Style： Panel mount

Mating Interface： Blind Mating Interface (BMI) for easy mating in hard-to-reach areas

Fastening Type： Push-pull (friction lock)

Housing Material： Polyamide (PA) / Nylon, UL94V-0 flammability rating

Operating Temperature Range： -40°C to +105°C

Color： Black

Mating Compatibility： Accepts Molex 46625 series male pin crimp terminals; mates with Micro-Fit 3.0 BMI receptacles (e.g., 46626 series)

Contacts： Not included (must be ordered separately)

RoHS Status： Compliant, lead-free

Applications：

The Molex 46625-0600 is suitable for a wide range of power and signal distribution applications, including:

Consumer Electronics

Home appliances (refrigerators, washing machines, microwaves)

Gaming consoles and entertainment systems

Industrial Equipment

Industrial control panels and automation systems

Power supplies and battery management systems

Renewable Energy

Solar panel interconnects and inverters

Energy storage systems

Automotive and Commercial Vehicle

Interior lighting and infotainment modules

Non-critical low-to-medium power distribution

Data Communications

Server and networking equipment power rails

HVAC Systems

Air conditioner control boards and fan assemblies

Note: To complete the connection, order the following separately:

Male Crimp Terminals: Molex 46625-0200 series (e.g., 46625-0201)

Mating Receptacle Housing: Molex 46626 series (e.g., 46626-0600 for 6-circuit)

Crimp Tool: Molex 63811-9300 or compatible hand crimp tool
