Description:

The LMZ21701 Nano Module is an easy-to-use step-down DC/DC solution capable of driving loads up to 1000 mA in space-constrained applications. Basic operation requires only an input capacitor, an output capacitor, a soft-start capacitor, and two resistors.

Features:

• Integrated inductor

• Micro 3.5mm × 3.5mm × 1.75mm package

• 35-mm² solution size (single-sided)

• Junction temperature range of -40°C to 125°C

• Adjustable output voltage

• Integrated compensation

• Adjustable soft-start function

• Starts up into a pre-biased load

• Power good and enable pins

• Seamless transition to power-saving mode

• Up to 1000 mA output current

• Input voltage range from 3V to 17V

• Output voltage range from 0.9V to 6V

• Efficiency up to 95%

• 1.5µA shutdown current

• 17µA quiescent current

• Create a custom design with the LMZ21701 using the WEBENCH® Power Designer

Applications:

• Point-of-load conversion from 3.3V, 5V, or 12V inputs

• Space-constrained applications

• Low-dropout regulator (LDO) replacement
