Product Description:

FT60F01X is a basic I/O type microcontroller series of Phaidon Microelectronics, which provides 1K*14b Flash, 256*8b data EERPOM and 64*8b SRAM, and supports 2.0V to 5.5V operating voltage. The microcontrollers provide up to six general-purpose IOs and two internal 8-bit timer/counters; built-in high-speed and low-speed RC oscillator, supporting a maximum frequency of 16MHz; and are available in both SOT23-6 and SOP8 packages, suitable for consumer electronics products with simple functions and very high cost requirements.

Application areas:

Consumer electronics, small home appliances, gifts and toys, etc.

CPU characteristics:

Operating voltage: 2.0V~5.5V

RISC architecture, only 37 instructions to learn

All instructions are single-cycle except branch jumps

Minimum instruction cycle is 250ns (VDD>2.7V)

Memory Architecture

Programme memory: 1K x 14bits

Data RAM: 64 x 8bits

Data EEPROM: 256 x 8bits

8-layer hardware stack

Low power mode SLEEP

Peripheral Characteristics:

Clock Source

16M high-speed high-precision HIRC

32K low-speed low-power LIRC

6 bi-directional IOs

Timer

1 x 8bit Timer0

1 x 8bit Timer2

16-bit watchdog with 7-bit prescaler

Power-on reset delay counter

Low Voltage Reset LVR: 2.0V/2.2V/2.8V

Support ISP and online debugging OCD

Operating temperature range: -40°C~85°C
