Product Description:

FT62F3GX is a high performance compact instruction set 8-bit touch microcontroller. It integrates 24 touch buttons internally and can be applied to touch-related products. On the analogue side, the chip contains a multi-channel 12-bit A/D converter, an op-amp and two comparators. In terms of protection, the chip contains internal protection features such as watchdog, low-voltage reset and low-voltage detection. In terms of communication interfaces, the chip integrates one I2C, one SPI and three UART interfaces. In addition the chip has 7 built-in timers/counters, of which 3 timers can be used for timing and generating PWM functions with 16bit resolution. The chip integrates 8x32 LCD/LED drivers containing 26 independently controlled IOs for applications requiring multiple IOs.

Application areas:

Electronic measuring instruments, household appliances, toys, etc.

CPU characteristics:

- Operating voltage: 1.9V - 5.5V

- Operating temperature range: -40°C - 85°C

- RISC architecture, only 75 instructions to learn

- All instructions are single-cycle except for branch jumps and individual instructions.

- Instruction cycle: 1T

- Minimum instruction cycle time is 62.5ns (VDD>2.7V)

- Memory Architecture

- Programme memory: 16K x 16bits

- Data RAM: 2048 x 8bits

- Data EEPROM: 128 x 8bits

- 31-layer hardware stack

- Low power mode SLEEP

- System clock can be optionally kept running or switched off

Peripheral Features:

- 24 touch keys

- Clock Source

- 13.5M/16M high speed high precision HIRC

- 32K low speed low power LIRC

- Crystal oscillator and external clock input

- Crystal clock miss detection

- 26 bi-directional IOs

- Timer

- 2 x 8bit basic Timer0/Timer1

- 1 x 10bit Timer2 with 3-bit prescaler

- 1 x 16bit Timer3 with 3-bit prescaler, support capture/compare/IR function

- 1 x 16bit Timer4, clock source selectable, with 3 prescalers, supports complementary PWM with deadband

- 2 x 16bit Timer5/Timer6, clock source selectable, with 3 prescalers, supports complementary PWM with deadband and 16-bit watchdog with 7-bit prescaler, clock source selectable

- Power-on reset delay counter

- 12-bit ADC with 26 external channels and 1 internal reference voltage channel

- Communication interfaces

- 1 x I2C

- 1 x SPI

- 3 x UART

- 2 comparators with 7-bit DACs

- 1 op-amp, output can be used as ADC channel

- 8x32 LCD/LED drivers

- Low Voltage Reset LVR: 2.0V/2.2V/2.5V/2.8V/3.1V/3.6V/4.1V

- Low Voltage Detect LVD: 1.2V/1.8V/2.0V/2.4V/2.7V/3.0V/3.3V/3.6V/4.0V or external input voltage

- Support ISP and online debugging OCD
