Description:

The GD32F307ZET6 is a high-performance microcontroller from GigaDevice's GD32F3 series, built on the Arm® Cortex®-M4 core operating at 120MHz with hardware FPU and DSP acceleration. With large memory capacity (512KB Flash, 128KB SRAM) and integrated connectivity including Ethernet MAC, USB 2.0 OTG, and CAN 2.0B, this MCU provides robust networking and processing power for data-intensive embedded applications. Housed in an LQFP144 package with extensive I/O, it is designed for industrial IoT, networked control systems, advanced motor drives, and other applications requiring reliable network communication, substantial code storage, and versatile peripheral interfaces.

Features:

Core: Arm® Cortex®-M4 processor @ 120MHz, with hardware FPU and DSP extensions

Large Memory: 512KB Flash and 128KB SRAM

Connectivity:

10/100 Ethernet MAC

USB 2.0 Full-Speed OTG

CAN 2.0B

Multiple UART, SPI, I2C, and I2S interfaces

Analog: 12-bit 2.6MSPS ADC (up to 24 channels), dual 12-bit DAC

Timers: Advanced-control, general-purpose, and basic timers, including motor control PWM

Package: LQFP144 (20x20mm)

Applications:

Industrial IoT Gateways and Network Controllers

Advanced Networked Motor Control Systems

Smart Home Hubs with Ethernet Backhaul

Data-Intensive Consumer Electronics with Network Connectivity

Medical Monitoring and Diagnostic Equipment with Network Interface

Automotive Telematics and Advanced Networked Control Modules
