Description：

The TPS51200DRCR is a sink and source double data rate (DDR) termination regulator specifically designed for low-input voltage, low-cost, and low-noise systems where PCB space is a critical consideration . It is fully compliant with DDR, DDR2, DDR3, DDR3L, LPDDR3, and DDR4 memory power requirements, providing up to 3A of output current for VTT bus termination . The device maintains fast transient response and requires a minimum output capacitance of only 20µF . It features remote sensing (VOSNS) for improved regulation accuracy and a buffered low-noise reference output (VTTREF). An open-drain PGOOD signal monitors output regulation, and the EN pin can be used to discharge VTT during S3 (suspend-to-RAM) states in DDR applications . The device is housed in a thermally efficient 10-pin VSON package with an exposed thermal pad and operates over a temperature range of -40°C to +85°C .

Features：

Sink and Source Termination Regulator specifically designed for DDR2, DDR3, DDR3L, and DDR4 memory termination .

Wide Input Voltage Range: 2.375V to 3.5V .

High Output Current: Up to 3A sink/source capability.

Fast Transient Response with minimum output capacitance requirement of only 20µF (typically three 10µF ceramic capacitors) .

Remote Sensing (VOSNS) for improved voltage regulation accuracy at the load point .

Buffered Low-Noise Reference Output (VTTREF) capable of ±10mA sink/source current .

Built-in Protection Features: Overcurrent limiting (OCL), undervoltage lockout (UVLO), and thermal shutdown .

Power Good (PGOOD) open-drain output for output monitoring.

Enable Control (EN) for VTT discharge during S3 suspend states .

Package: Thermally efficient 10-pin VSON package (3mm x 3mm) with exposed thermal pad .

RoHS Compliant and Lead-Free .

Applications：

DDR, DDR2, DDR3, DDR3L, LPDDR3, and DDR4 memory termination regulators .

Notebook computers, desktop computers, and servers.

Telecommunications and data communications equipment .

Base stations and networking infrastructure .

Consumer electronics: LCD TVs, PDP TVs, set-top boxes, copiers, and printers .
