Overview：

The LM76005-Q1 regulator is an easy-to-use synchronous step-down DC/DC converter capable of driving up to 5A (LM76005-Q1) of load current with an input voltage up to 60V. With a tolerance up to 65V, it helps facilitate input inrush current protection. The LM76005-Q1 employs peak current mode control to deliver excellent efficiency and output accuracy with a very small solution size. Seamless transition between PWM and PFM modes, combined with ultra-low MOSFET on-resistance and an external bias input, ensures exceptional efficiency across the entire load range. The device requires very few external components, and its pins are designed to simplify PCB layout, providing excellent EMI (CISPR25) and thermal performance. The small solution size and feature set of the LM76005-Q1 are designed to simplify implementation across a wide variety of end equipment. The LM76005-Q1 is available in a 30-pin WQFN package with wettable flanks.

Features：

AEC-Q100 qualified for automotive applications

Temperature Grade 1: –40°C to +125°C, TA

Functional safety available

Documentation to aid functional safety system design

Designed for automotive applications

Up to 65V input transient protection

Optimized to meet low EMI requirements

Pin-selectable FPWM operation

Adjustable frequency range: 200 kHz to 500 kHz

Start-up into pre-biased output voltage

Protection features: thermal shutdown, input undervoltage lockout, cycle-by-cycle current limit, and hiccup short-circuit protection

Scalable power supply solution

Pin-compatible with:

LM76002/3-Q1 (60V, 2.5A or 3.5A)

Output voltage: 1V to 95% of VIN

Synchronizable to an external clock

Adjustable soft start (default 6.3 ms)

Low power dissipation across the entire load range

Standby quiescent current: 15 µA

95% efficiency at 400 kHz (12VIN, 5VOUT, 2A)

92% PFM efficiency at 10 mA (12VIN, 5VOUT)

External bias option for improved efficiency

Create a custom design using the LM76005-Q1 with WEBENCH® Power Designer

Applications：

Automotive ADAS supporting 24V batteries

Infotainment and instrument clusters

Hybrid electric vehicles (HEV) / Electric vehicles (EV)
